Before we continue with our Home Server Scripting Series, let's throw in a simple but useful DTrace hack.
One of the most typical uses for a home server is to serve music or videos to home entertainment equipment. In my case, I'm using the Firefly Media Server to serve music to my Roku Soundbridge and Mediatomb for videos.
The Media Server Update Problem
Whenever I upload new music or videos to my OpenSolaris home server (typically by rsync-ing my laptop home directory), both Firefly and Mediatomb need to be restarted so they detect that new files are sitting in their directories, waiting to be served.
The typical way to solve this in the Linux world is to use inotify, and it seems to work quite well. But inotify is a Linux-only API and it is therefore not portable.
The OpenSolaris way to detect changes in the file system is through file notification events. Darren Moffat has written a nice tutorial on how to use file notification events in your code. But this code has not been adopted by neither Firefly nor Mediatomb (yet?).
A Simple Media Server Update Solution
There's another way, more simple than coding file notification events and easy to use for any kind of media server software: DTrace.
In the following script, we'll ask DTrace to watch for
open(2) events and filter out those that match the directories where we store our media. Then, when new files come in or are changed we'll send
SIGHUP signals to our media server processes so they can re-scan their content directories.
Some Useful DTrace Principles
While putting together this DTrace script, the following things came up which are probably useful to know for a variety of similar D scripts:
DTrace already knows about the standard
libcand kernel functions, so, when watching out for writes, we can just specify the
open(2)verbatim without knowing their actual values.
To match the media directory with the path given to
open(2), we need to look at
arg0, which is a pointer to the given file name. But the file name resides in user space while DTrace operates in kernel space. Therefore, we need to use the DTrace
copyinfunction to copy the file name across memory spaces. This is a common DTrace technique described in the User Process Tracing chapter of the DTrace documentation.
Another common thing to keep in mind: At the moment of function entry, the file name may reside on a memory page that is not yet accessible, so we can't necessarily read it yet. We therefore capture the value of
arg0at function entry time, wait until the function has completed, then read out the file name which will then be accessible for sure. Again, this is described in the same chapter of the DTrace docs.
When trying to match the arguments to
open(2)with the media directory we want to watch, we need to test for two cases: 1)
arg0contains the full path, or 2)
arg0is relative to the current working directory. In the latter case, we need to construct the full path, then test against it.
If we add half a dozen CDs and 100 songs to our media library, we don't want to force a re-scan 100 times. We'll therefore use a flag that indicates that we have detected some new files, then test against the flag periodically (say, every minute or so) and only then signal the media server process to re-scan.
In order to make the burden on the system as light as possible, we'll try to do as much of the testing as possible inside of DTrace predicates and only use action statements where necessary. Also, DTrace supports short-circuiting of logical
ANDtests, so we'll place the most likely or common tests at the beginning of our predicates.
We'll use the DTrace
system()action to signal our media server processes. This is a destructive action (well, not really, but in DTrace parlance...) which means we'll need to use the
dtrace(1M)which enables destructive actions.
The Automatic Re-Scan DTrace Script
With that in mind, let's look at the final DTrace script:
Usage and Testing
The script accepts two arguments: A directory to watch and a command that is executed when a file is opened for writing inside the directory. A typical use of this script looks like this:
-bash-3.2$ pfexec ./dirtrap.d /home/constant/PowerBookHome/Music/iTunes "pkill -HUP mt-daapd"
And after having touched a file inside our directory with a simple:
-bash-3.2$ echo "test" >/home/constant/PowerBookHome/Music/iTunes/testfile
We see this after a couple of seconds in the mt-daapd log file:
Apr 19 22:38:03 mt-daapd mt-daapd: [ID 702911 daemon.alert] Got HUP signal. Apr 19 22:38:03 mt-daapd mt-daapd: [ID 702911 daemon.alert] Rotated logs Apr 19 22:38:03 mt-daapd mt-daapd: [ID 702911 daemon.alert] Rescanning database 2010-04-19 22:38:03 (00000001): Rotated logs 2010-04-19 22:38:03 (00000001): Rescanning database Apr 19 22:38:12 mt-daapd mt-daapd: [ID 702911 daemon.alert] Starting playlist scan 2010-04-19 22:38:12 (00000001): Starting playlist scan Apr 19 22:38:22 mt-daapd mt-daapd: [ID 702911 daemon.alert] Updating playlists 2010-04-19 22:38:22 (00000001): Updating playlists Apr 19 22:38:24 mt-daapd mt-daapd: [ID 702911 daemon.alert] Scanned 7175 songs (was 7175) in 21 seconds 2010-04-19 22:38:24 (00000001): Scanned 7175 songs (was 7175) in 21 seconds
Looks like this script is doing its thing. Now I'm waiting for my next load of CDs to arrive so I can rip and
rsync them into my auto-updating OpenSolaris home media server!
DTrace can be an amazing help for any system administrator, even on a home server. In this case, we've fixed a common problem that other OSes would need a whole new API (like inotify) to address this problem with!
Learning DTrace isn't that hard if you look at existing D scripts, check out the documentation and are not afraid to read the occasional line of OpenSolaris source code.
Other Useful DTrace Home Server Scripts
This is just the beginning. In fact, if you look around, there's a wealth of opportunities to leverage DTrace in your day to day work, even in your home server. Here are a few famous examples:
opensnoopis a more sophisticated version of the above, without the
system()part, though. Make sure to check his other DTrace tools as well!
Chris Gerhard has a wealth of DTrace related articles, just look for the dtrace tag. You may also prefer browsing his old blog, as some of the scripts didn't survive the migration to Wordpress very well. My favourites are "Snapshot on unlink?" and "Monitoring mounts".
For my German speaking readers: Raichoo has written a wealth of useful DTrace articles in German language in his blog. Great stuff!
But that's not enough. Googling "DTrace home server" doesn't reveal much at the moment. So now it's your turn:
If you haven't played with DTrace start exploring it now!
Did you write yourself some useful D scripts already? Blog them! Or share them in the comments below!
What other situations can you imagine where DTrace would be helpful to you home server?
As always, feel free to share your experiences and comments below.
Thanks to this post, I discovered that DTrace translators can help identify the file name no matter whether it was relative or not. That makes the predicate for
syscall::open*:return much simpler:
/ !flag && /* Exit if we've already found a hit. */ self->file && /* Exit if we didn't take an arg0 note. */ substr(fds[arg0].fi_pathname, 0, dirlen) == dir /* Check directory */ /
I need to look closer at those translators as they seem to be very useful.
